Please kindly offer urgently following FLEXOWELL equivalent products.

1. Flexowell XOE 800/5+1 Corrugated Sidewall Conveyor Belt

- Number of Belt Required: 2 complete belts with sufficient numbers of free sidewall/cleat for joint area and splicing materials

- Belt Width: 1200 mm

- Belt Length: 116 m (total open end length including overlap)

- Base Belt Specification: XOE 800/5+1

- Rubber Covers, Top:Bottom: 4.0:2.0 mm

- Flexowell Sidewalls, height/type: 240 S

- Spceial Fabric Reinforcement Cleat, height/type: 220 TCS

- Screw Reinforcement to Sidewalls Pitch Longitudinal: 250 mm

- Base Belt Propoerties (Tests According to DIN 53530)

-- Adhesion between Ply to Ply: mean value >/= 10 N/mm

-- Adhesion between Ply to Cover: mean value >/= 8 N/mm

- Rubber Cover Properties

-- Tensile Strength: mean value >/= 20 N/ mm2

-- Elongation at Break: mean value >/= 350%

-- Hardness: mean value +/- 4 @78 Shore A

-- Abrasion: mean value

-- Density: +/- 0.02 @1.13 g/cm3

- Complete Belt Porperties

-- Breaking Strength Longitudinal: >/= 800 N/mm

-- Breaking Strength Transverse: >/= 400 N/mm

-- Elongation at Break Longitudinal: +/- 3 @13%

-- Elongation at Break Transverse: +/- 6 @20%

2. Flexowell XOE 500/3+1 Corrugated Sidewall Conveyor Belt

- Number of Belt Required: 2 complete belts with sufficient numbers of free sidewall/cleat for joint area and splicing materials

- Belt Width: 800 mm

- Belt Length: 34 m (total open end length including overlap)

- Base Belt Specification: XOE 500/3+1

- Rubber Covers, Top:Bottom: 4.0:2.0 mm

- Flexowell Sidewalls, height/type: 240 S

- Spceial Fabric Reinforcement Cleat, height/type: 220 TCS

- Screw Reinforcement to Sidewalls Pitch Longitudinal: 315 mm

- Base Belt Propoerties (Tests According to DIN 53530)

-- Adhesion between Ply to Ply: mean value >/= 8 N/mm

-- Adhesion between Ply to Cover: mean value >/= 6 N/mm

- Rubber Cover Properties

-- Tensile Strength: mean value >/= 20 N/ mm2

-- Elongation at Break: mean value >/= 350%

-- Hardness: mean value +/- 4 @78 Shore A

-- Abrasion: mean value

-- Density: +/- 0.02 @1.13 g/cm3

- Complete Belt Porperties

-- Breaking Strength Longitudinal: >/= 500 N/mm

-- Breaking Strength Transverse: >/= 250 N/mm

-- Elongation at Break Longitudinal: +/- 3 @13%

-- Elongation at Break Transverse: +/- 6 @20%

We look forward to receiving a competitive offer for equivalent product shortly.

Regards,

Derek T. S. Lian

Giant Ray International Co., Ltd.

11F-1, No. 379 Jung Shan Road

San Chong City, Taipei 241

TAIWAN

Tel.: +886-2-8511 2556

Fax: +886-2-8511 2557

E-mail : giantray@ms1.seeder.net ■
