Re: Efficiency Of Ball Mills Vs. Roller Mills
The answer is a litle bit complex. The specific grinding power consumption for the tube mill for cement grinding can vary a lot.
A brief list of factors that influence both the mill production and the power consumption can be listed:
- grinding circuit (open or close)
- type of cement
- clinker composition (C2S:C3S) ratio
- clinker temperature
- percentage of clinker with grain size lower than 2 mm
- If slag or other additives are used
- grinding fineness of the cement
- if operate in closed circuit - what is the type of separator
- cement collecting system
- tube mills internal equipment (proper designed diaphragm and linings)
- tube mill driving system.
- cement collecting system
For a proper designed cement grinding department with tube mill, the department specific power consumption for producing OPC at 3200 Blaine can be 38-45 kWh/t
For vertical mill - 35-42 KWh/t
The main aplication for vertical mills for cement grinding was considered as a pregrinding unit for large capacities ■
Pay Attention To Our Milling Equipment
Dear sir,
you intrest in ball mill and roller mill,yes,we may offer you many kinds of mills,if you want to know more information,please view:
href="http://www.zenithcrusher.com" target="blank">http://www.zenithcrusher.com
href="mailto:cassidy886@gmail.com">cassidy886@gmail.com
Attachments
■
Re: Efficiency Of Ball Mills Vs. Roller Mills
It depends, I give the power consumption range as below:
Power consumption for ball mill: 20 - 450 KW
Power consumption for roller mill: 20 - 75 KW
Following link for your reference.
href="http://www.sbmchina.com/products/Grinding/ballmill.html" target="blank">http://www.sbmchina.com/products/Gri...ballmill.html
href="http://www.sbmchina.com/products/Grinding/highmill.html" target="blank">http://www.sbmchina.com/products/Gri...highmill.html
Attachments
■
Re: Efficiency Of Ball Mills Vs. Roller Mills
Dear Shibang:
Approximate values at 3000 Blaine are
Ball mill 26 kWh/t
Roller mill 17 kWh/t
Roll press 13 kWh/t
Eberhard Neumann
www.koppernusa.com ■
Untitled
for the same production rate what is the power consumed in these mills ? ■
Various Grinding Equipments Offers By Hongji Group
Dear sir,
We offers varous grinding machinery such as ball mill, rod mill and crushing machinery such as roll crusher, hammer crucher and other machineries.
if you have the need of a mill, you can visit us for more detailed information. ■
Efficiency of ball mills vs. roller mills
I would like to know if anybody knows the power consuption in KW per ton of a ball mill milling cement clinker at a feed of 1" minus in order to produce Portland Cement. I would also like to get the same info for a roller mill. ■
